Draeger MT Trichlorethylene 0.25-50 ppm - PN : 8610320

Add Your Review
$98.50

Draeger MT Trichlorethylene 0.25-50 ppm

PN : 8610320


Measuring Range
 0.25 to 50 ppm
Typical Measuring Time
 20 to 270 s
Accuracy  ± 25% ( under calibration conditions )
Ambient Conditions
Temperature
 0 to 40 °C
Humidity
 1 to 40 mg/L
Cross Sensitivity
 No influence at 0.5 ppm sulfur dioxide by:
500 ppm n-octane
5 ppm hydrochloric acid
Hose and probe measurement
 The following flushing time recommendations for hose and probe measurement are marked with a brand-new , dry and clean hose  and probes.



 Hose
 Length ( meter )
 Flashing time (min)
FKM hose
 5 - 20
 3
FKM hose
 45
 5
PTFE-line PVC hose
 3 - 15 3
Bar probe 90 (83 16 532)
2
Telescopic probe ES 150 ( 83 16 533)
2
Probe set GP600 )83 28 667)
2
